FR4 Rigid PCB

FR4 Rigid PCB

FR4 Rigid PCB is Solid, inflexible Printed Circuit Board. PCB can be Single or Double Sided PCB or Multilayer PCB.At the same time a Printed Circuit Board can be Rigid, Flexible or Rigid-Flex (Combination of Rigid and Flexible PCB). So, Rigid Circuit Board is a Board that we cannot bend or force out of shape. It is not flexible.Keywords:FR4 Rigid PCB, Manufacturers, Suppliers, Factory, Customized, Free Sample, China, Made in China, Cheap, Quotation, CE, Quality, 2 Years Warranty

Send Inquiry

Product Description

1. Product Introduction of the FR4 Rigid PCB

Quint tech offer PCB production services from 1-36 layers, material could be FR4,High TG FR4,rigid PCB.


2. Product feature and application of the FR4 Rigid PCB


Max Rigid PCB size
 1100*650mm, Min PCB size: 5*10mm
Min board thickness
 0.3mm (2 layers)/ 0.5mm (4 layers)/0.8mm (6 layers)/ 1.2mm (10 layers)/1.3mm (12 layers)/1.5mm (14 layers)/1.7mm (6 layers)/1.8mm/2.0mm (18 layers)/2.2mm (20 layers)/2.4mm(22 layers)/2.6mm (24 layers), etc
The tolerance of board thickness
 board thickness＞1.0mm，±10%，board thickness≦1.0mm,±0.1mm.
Max copper thickness
 8oz/inner layer,8oz/out layer
Min inner line width/space
 0.076mm/0.076mm


3. Product Qualification of FR4 Rigid PCB

During the FR4 Rigid PCB production, we have circuit test-Withstand voltage test-OSP.


After these test, there have FQC-FQA-Pack-shiping.
